Q.Max QMA-28.3M Sheet Metal Punch 28.3mm QMA283M
Stock Code:
QMA283M
Q.Max QMA-28.3M Sheet Metal Punch 28.3mm QMA283M
Stock Code:
QMA283M
View All: Taps Dies & Punches
View All Q.Max Products
£20.38
Excl. VAT
£16.98
Excl. VAT
Available - Delivery within 3-4 Working Days
Description
Specification
Delivery
Returns
Finance Options
Reviews
Size.28.3mm.
Key Type.MB. 8mm hexagonal wrench
A quick and easy way to cut clean metric sized holes in sheet metal up to 16 gauge.
The special design allows even load during cutting and produces a burr free hole that needs no extra finishing.
Heat treated cutting edges with black anti-corrosive surface finish to prevent rusting.
All punches are sold singly without key, which should be ordered separately.
Thread the punch onto the hexagonal screw and then pass the hexagonal screw through the hole. Position the die on top of the die nut and then screw the die nut onto the projecting hexagonal screw until it touches the metal sheet. Use a hexagonal key to turn the hexagonal screw. The screw will pull the punch through the metal and a hole will result.
Please note these instructions apply to cutters up to 15 mm in size, for cutters 15 mm and over have a different configuration. Notably they have fewer components, in the larger cutters the thread is in the punch and thus there is no die nut.
Q.Max
A01
B0003
Brand: Q.Max
Category: Metal Punches
Height (mm): 105
Width (mm): 47
Depth (mm): 177
Weight: 0.183
Punch Type: Metric
Diameter (mm): 28.3
Key Type: MB. 8mm Hex Key
Pilot Drill (mm): 11
EAN: 5055995599140
Buyaparcel offer delivery throughout the United Kingdom, including Northern Ireland, Scottish Highlands and other Islands of the UK. We do not currently ship overseas.
UK Delivery Prices
Standard delivery is free with no minimum order charge to most mainland UK delivery addresses. Surcharges can apply to certain postcodes depending on the service type. For full details visit our Delivery Guide.
In additional to our standard service we also offer some premium delivery services if you need your item quickly
£0.00 - Standard UK Delivery (2-3 Days Approx)
£2.99 - Next Day UK Delivery (Orders placed before 3.00pm Monday - Friday)
*orders placed after 3.00pm Friday will still be delivered Monday if ordered before 11am Saturday Morning
£8.99 - Saturday Delivery (Orders placed before 3.00pm Friday)
£36.00 - Pallet Delivery (2-3 Days Approx - selected products only)
Alternatively if you view your parcel once items have been added and enter your postcode you will see what derlivery services are available.
Is My Item Available for Next Day Delivery?
If your item is stocked in our immediate picking location it will available for you to choose a next day delivery. This will be highlighted by a green tick and a 1 day dispatch time on the item information.
You will have the option to choose this service if you are purchasing your item for delivery to mainland UK.
What courier will my item be delivered with?
If your item is being delivered in the UK or Ireland, it will be delivered by DHL eCopmmerce UK, Evri or Royal Mail, with the exception of pallet items.
Details of each courier service we offer are detailed in our Delivery Guide.
Is My Item Available for Click and Collect at your Lowestoft Store?
If your item is showing "In Stock" then you will be able to do a Same Day Click and Collect order from our Lowestoft Pinbush Road. Our cut off for same day collections is 3.00pm Mon-Fri / 11.00am Saturday. After that the product will be ready the next day for collection. After the cut off you are welcome to do a Call and Collect order by phoning our trade counter on 01502 507666. If your item is in stock you will still be able to do a same day collection and payment.
Our store is open Monday to Friday 8.00am - 5.00pm and Saturday 8.00am - 12.00pm so any orders placed the remainder of the weekend will be available for collection on Monday. Weekdays any orders placed up to midnight will be available for collection the following day. This excludes bank holidays.
Please wait for email confirmation your order is ready for collection from our store before you travel.
On collection we will require you to show a copy of your order confirmation, electronic or printed. In addition to this please bring photo ID which must be your passport or photo driving licence, matching the name on the PayPal/Amazon/Credit or Debit card used.
Collection option only available to NR and IP Postcodes
We've simplified our returns process! We now offer a no-questions-asked, free returns service within the first 30 days (subject to T&Cs).
You can find our returns information in our Terms and Help page
Spread the cost of your Buyaparcel purchase with Paypal Credit - Get 0% finance over 4 months! The perfect way to spread the cost of any purchases of £99 (inc vat) or more
Applying is that simple. If approved and you accept, you'll have a credit limit added to your PayPal account ready to use immediately. Plus, you'll automatically get 0% interest for 4 months on all your purchases of £99 or more.*
How to apply for Paypal Credit with Buyaparcel?
You have 2 ways to purchase from us with the option us using Paypal Credit.
1 - From the product page you can use Paypal Express Checkout which will take you straight to your Paypal account where you can login to complete payment or apply for Paypal Credit.
2 - If you add your product to your parcel and click "Proceed to Checkout" you will then go to our payment page. Select "Paypal Express Checkout" from the payment methods available and click "Place Order".
Once you are in your Paypal account choose PayPal Credit from the payment options.
If this is the first time you have used PayPal Credit, you will be asked to complete a short application form to apply for PayPal credit.
More Information on Paypal Credit
Write Your Own Review
Description
Size.28.3mm.
Key Type.MB. 8mm hexagonal wrench
A quick and easy way to cut clean metric sized holes in sheet metal up to 16 gauge.
The special design allows even load during cutting and produces a burr free hole that needs no extra finishing.
Heat treated cutting edges with black anti-corrosive surface finish to prevent rusting.
All punches are sold singly without key, which should be ordered separately.
Thread the punch onto the hexagonal screw and then pass the hexagonal screw through the hole. Position the die on top of the die nut and then screw the die nut onto the projecting hexagonal screw until it touches the metal sheet. Use a hexagonal key to turn the hexagonal screw. The screw will pull the punch through the metal and a hole will result.
Please note these instructions apply to cutters up to 15 mm in size, for cutters 15 mm and over have a different configuration. Notably they have fewer components, in the larger cutters the thread is in the punch and thus there is no die nut.
Q.Max
A01
B0003
Specification
Brand: Q.Max
Category: Metal Punches
Height (mm): 105
Width (mm): 47
Depth (mm): 177
Weight: 0.183
Punch Type: Metric
Diameter (mm): 28.3
Key Type: MB. 8mm Hex Key
Pilot Drill (mm): 11
EAN: 5055995599140
